The ASM 03102344 is a high-performance ceramic-tipped nozzle designed for the SIPLACE TX, SX, and X-series high-speed placement gantries. Specifically optimized for the 4107 and 6107 nozzle series, this component is the interface between the placement head and the component. Its design features a Micro-Aperture Vacuum Core, engineered to provide maximum holding force on miniature passive components while maintaining a lightning-fast vacuum release cycle.
GEEKVALUE provides the 03102344 with a focus on Material Longevity. We understand that in high-CPH environments, nozzle tip wear is the leading cause of "No-Pick" and "Component-Fly" errors. Our nozzles are manufactured with Hardened Tech-Ceramic Tips, ensuring that the pick-up surface remains perfectly flat and perpendicular to the component axis over millions of cycles.
Technical Specifications
Feature | Technical Data |
Product Type | High-Speed SMT Placement Nozzle |
Part Number (P/N) | 03102344 |
Nozzle Series | 4107 / 6107 |
Compatible Heads | SIPLACE CP20 (PowerHead), CP12 (HighSpeed Head) |
Tip Material | High-Grade Anti-Static Tech-Ceramic |
Application Range | 0201 (Metric), 0402, 0603, and Ultra-Fine Pitch ICs |
Identification | Integrated Data Matrix / Shaft Recognition Geometry |
Strategic Performance Advantages
· Integrated Anti-Static (ESD) Shielding: The 03102344 is coated with a proprietary dissipative layer. This prevents the build-up of electrostatic charges during high-frequency picking, ensuring that tiny components do not "stick" to the nozzle tip during the placement stroke—a common cause of tombstoning in 01005 assembly.
· Dynamic Vacuum Flow Geometry: The internal air path is CNC-machined to minimize turbulence. This ensures that the vacuum reaches its peak holding pressure in milliseconds, allowing the SIPLACE gantry to move at maximum acceleration without the component shifting or rotating during transit.
· Self-Cleaning Orifice Design: The 03102344 features a refined tip geometry that resists the accumulation of solder paste and flux residues. This reduces the frequency of nozzle cleaning cycles and prevents the vacuum blockage that often leads to intermittent pick-up failures.
· High-Resolution Visual Contrast: The matte finish of the ceramic tip is designed to provide a high-contrast background for the SIPLACE vision system. This allows the machine's "Component-on-Head" camera to accurately identify the component's center and orientation with sub-micron precision.
The GEEKVALUE Advantage: "Precision at the Point of Impact"
1. 360° Total Cost Optimization (TCO)
The nozzle is the most frequently replaced "wear part" on an SMT line. GEEKVALUE optimizes your TCO by providing 03102344 Nozzles that have undergone Vacuum Leakage Audits. By delivering a nozzle that maintains its suction integrity longer than standard aftermarket parts, we reduce your machine downtime and the cost-per-placement.
2. Trusted by 400+ Public Companies
Global leaders in high-end smartphone and medical device manufacturing trust GEEKVALUE for their nozzle infrastructure. Our 03102344 units are the preferred choice for listed companies that require "Absolute Pick-and-Place Reliability" on their high-density, high-volume production lines.
3. Optimized for High-CPH Performance
GEEKVALUE’s 03102344 nozzles are inspected for Shaft Concentricity and Tip Flatness. We ensure that the nozzle docks perfectly with the head's exchange system, providing a "Plug-and-Play" experience that allows your SIPLACE machine to operate at its theoretical maximum speed.
Frequently Asked Questions (FAQ)
Q1: Is the 03102344 nozzle compatible with the SIPLACE TX2 CP20 head?
Yes. It is fully compatible with all modern SIPLACE CP20 and CP12 heads used in the TX, SX, and X series machines.
Q2: How does GEEKVALUE verify the ESD properties of the nozzle?
Every nozzle is tested with a Surface Resistivity Meter. We verify that the ceramic tip falls within the dissipative range ($10^5$ to $10^9\text{ ohms}$), ensuring it safely handles sensitive semiconductors.
Q3: Can these nozzles be used for 01005 (0402 Metric) components?
While the 03102344 (4107/6107) is highly versatile, for ultra-small 01005 parts, GEEKVALUE recommends verifying the tip diameter matches your specific component footprint to avoid vacuum leakage.
Q4: How often should the 03102344 nozzle be cleaned?
In a 24/7 high-speed environment, GEEKVALUE recommends a Weekly Ultrasonic Cleaning and an automated "Nozzle Health Check" every shift to maintain optimal vacuum flow.
Q5: What is the packaging standard for SIPLACE precision nozzles?
We use Individual ESD-Safe Protective Capsules. Each 03102344 is housed in a rigid, anti-static container to ensure the delicate ceramic tip and identification shaft arrive in perfect factory condition.
